The 800VAC Solar Type Tested Panel is an essential component in solar power systems, facilitating the distribution, control, and protection of electrical power generated by photovoltaic (PV) modules. It is designed to handle high voltages typical of large-scale solar installations and integrates various components to optimize performance and ensure safety.
Constructed from high-quality steel.
Offers protection against environmental factors such as dust, moisture, and UV radiation.
Equipped with ventilation or cooling systems to manage heat dissipation.
Meets high IP ratings (e.g., IP65 or higher) to ensure ingress protection.
Circuit Breakers and Fuses
Protect the panel and connected circuits from overcurrent, short circuits, and ground faults.
DC-rated circuit breakers for solar input and AC-rated breakers for output.
Busbars
Made from copper or aluminum to efficiently handle high current loads.
Designed to minimize power loss and ensure reliable power distribution.
Surge Protection Devices
Protect the panel and connected equipment from voltage spikes and transient over-voltages.
Critical for safeguarding sensitive solar equipment from lightning strikes and other surges.
Meters and Monitoring Equipment
Measure and display electrical parameters such as voltage, current, power output, and energy production.
Enable real-time monitoring and data logging for performance analysis.
Disconnect Switches
Allow safe isolation of the solar array or individual circuits for maintenance and emergency shutdowns.
DC and AC disconnects ensure comprehensive safety.
Inverter Connections
Provide integration points for solar inverters, which convert DC power from solar panels to AC power for distribution.
Include necessary protection and filtering components to ensure clean power output.
Protection Relays
Monitor system parameters and trip breakers or disconnects in case of faults.
Ensure the protection of the system and prevent damage to equipment.
Combiner Boxes
Aggregate inputs from multiple strings of solar panels.
Include overcurrent protection and monitoring for each string.
Application
01
Utility-Scale Solar Farms
Distribute power generated by large arrays of solar panels.
02
Commercial and Industrial Solar Installations
Manage power from rooftop or ground-mounted solar systems.
03
Microgrids
Integrate solar power into localized grids for enhanced reliability and resilience.
Rating
Voltage Rating
The panel is designed to handle a voltage of 800V AC. The 800V rating would be suitable for systems where higher voltage levels are necessary for specific solar project.
Current Rating
The current-carrying capacity would be specified based on the total load and the application requirements.
Advantages
High Efficiency
Optimized for minimal power loss and maximum energy transfer.
Enhanced Safety
Rigorous testing ensures protection against electrical faults and environmental hazards.
Reliability
Designed for long-term operation with minimal maintenance.
Scalability
Suitable for both large and small solar power installations.
High Efficiency
Optimized for minimal power loss and maximum energy transfer.
Enhanced Safety
Rigorous testing ensures protection against electrical faults and environmental hazards.
Reliability
Designed for long-term operation with minimal maintenance.
Scalability
Suitable for both large and small solar power installations.
